All Types of Machines
-
1/6 Watering Saving System Irrigation Sprinkler Rain Hose Irrigation System Micro Spray Hose
Item No.
SD1415C
Size
2″ flange
Nozzle Diameter
20/22/24/26/28/30mm
Working Pressure
2-8bar
Shoot Radius
28-62m
Flux
21-107.9m3/H
Feature and Application
>Designed with water diffuser for main nozzle, and wheel for second nozzle, it bring with more even water, and working like the rain, better for small plants irrigation;
>With different nozzle for choice, with long shoot distance;
>With elevation angle 23 degree;
>Made by cooper alloy, aluminum alloy, engineering plastics, stainless steel and other corrosion-resistant materials;
>Widely used for farmland irrigation or industrial dedusting;
>Durable, stable performance, uniform spray;₨ 39,999₨ 60,000 -
Hunyadi 4 Storke , 25 liter Capacity Only Use for agriculture sprayers
Categories:
Machinery, Power Sprayer
Tag:
Power Spray
₨ 38,850 -
-
Cultivator 11 Tines
General Specification
Special Model, Export Quality
Tractor Mounted
-(65hp or above)
For cultivation of soil
No. of Tines: 11 no.
Shear: Hardened steel
2590mmX830mmX1030mm +10mm(L
–
W
-H)
Mast A
-Fram: M.S Angle Iron
Paint: Double coat with primer after surface finish Weight
approximately400kg(+10kg)₨ 160,950Cultivator 11 Tines
₨ 160,950 -
Multi-Crop Bed Planter.png
General Specification
Special Model, Export Quality
Tractor Mounted-(50hp or above)
Link category II
For Sowing of: wheat, Maize, Pulses, Sorghum, Chick peas, Soya beans
etc. with fertilizer application.
Number of Rows – 4 ( making 2 Beds)
Row Spacing – Adjustable
Length – 1600 mm
Width – 2430 mm
Height – 1200 mm
Material Specifications ;
Main Frame – M.S formed sheet 5 mm with side support of same size
Mast ( A – Frame ) M.S formed sheet 8 mm reinforced with 9 mm M.s
flat at top ends, fitted with M.S flat 50* 12 mm
Hitch – M.S box 100 * 5 mm or 95*45*5 mm MS rectangular pipes
Furrow / Ridger – M.S sheet 6.5 mm
Shear – MS plate 8 mm
Row Maker – 02 Numbers ( 50*50*4 mm)
Seed Units – 04 numbers ( Imported ) 10 breaks ( for small seeds like
millet, Raya seed units can be replaced )
Seeder Frame – MS square pipe 58*58*4 mm, MS box 38*38**4 mm
seeder arm on each unit welded with MS angle75*75*4 mm, 08
numbers, MS 18 mm diameter pipes 12 Guage/ MS 18 mm road
Fertilizer Hoper – MS sheet 18 guage with angle support 48*48*4 mm
metering unit 04 Nos. fluted wheel rectangular plates.
Ground Wheel – M.S. flat 75*6 mm with 5 mm M.S. sheet with hub,
450 mm diameter with spikes of 19 mm diameter. M.S. rod 50 mmlong ,
02 numbersbearing of 6206, chain # 50
Accessories – 02 numbers of seeder unit ( Dibbler type)
Origion – Local
Paint – Double coated with primer after surface finish
Nuts and Bolts – To be Tightened with Spring washels
Bearings – European Standard₨ 320,000Multi-Crop Bed Planter.png
₨ 320,000 -
Multi-Crop Seed Drill Machine- 9 Tines
Special Model, Export Quality
Tractor Mounted-(50hp or above)
Link category II
For Sowing of: wheat, Maize, Pulses, Sorghum, Chick peas, Soya beans etc.
Seed Metering system: Fluting Plates
Fertilizer Metering system: Fluted Roller Type (Forged made with metal brass).
Overall width 2280mm (working width 1820mm) Number of Rows: 09 with adjust
row spacing and hardened
Sowing Depth: Adjustable with 02 nos. depth control wheels.
Drive wheel: 01 fitted on rear end of seed drill.
Seed capacity: 18kg or above
Fertilizer capacity: 100kg or above
Bearings: European standard or Equivalent
Paint: Double coat with primer after surface finish Weight approximately
350kg(+5kg)₨ 305,250Multi-Crop Seed Drill Machine- 9 Tines
₨ 305,250 -
Wheat Seed Drill Machine (zero Tillage seed Drill) -13 Tines
With Adjustable Front Depth control system
General Specification
Special Model, Export Quality
Tractor rear Mounted-(50hp or above)
Link category II
For Sowing of wheat.
Seed & Fertilizer Metering system: Fluted Roller Type (Forged made with metal brass).
Overall width 2180mm (working width 1820mm)
Number of Rows: 13 with adjust row spacing and hardened
Sowing Depth: Adjustable with 02 nos. depth control wheels.
Drive wheel: 01 fitted on rear end of seed drill.
Seed & Fertilizer capacity: 100kg or above
Seed & Fertilizer Rate: Adjustable with clutch type system from 20kg to 60kg/ acre
Bearings: European standard or Equivalent
Paint: Double coat with primer after surface finish Weight approximately 440kg(+5kg)₨ 194,250 -
-
Chisel Plough 7 Tines
General Specification
Special Model, Export Quality
Type: Mounted Box frame type
No. of tines: 07
Tractor Power requirement: 50hp or above
Tine Spacing: 375mm and 670mm (+10mm)
750mmX1300mmX1400 (+10mm)
Main V-Frame: 1400x110x5mm, made from M.S Formed Sheet
box type.
Mast A-frame:12mm M.S plate , 100mm wide
Tine: 820x180x30mm M.S plate with three depth adjustment
grooves
Cutting wedge on tine: 400x30x50mm hardened steel
Paint: Double coat with primer after surface finish₨ 144,300Chisel Plough 7 Tines
₨ 144,300 -
Rotavator- 60 Blades
General Specification
Special Model, Export Quality
Tractor Mounted-(75hp or above)
P.T.O Driven(U.J Shoft 1no.), Link category II
Working width2275mm
Rotor speed (min). 230-245 rpm @540 PTO speed
1000X2600X1000mm (LxWxH)
L-shaped, forged, heat treated, 5-6 mm thick,HRC 40
Water Tight
Weight approximately 600kg₨ 305,250Rotavator- 60 Blades
₨ 305,250 -
Disc Plough- 3 Disc
General Specification
Special Model, Export Quality
Tractor Mounted-(60hp or above)
For Deep tillage of hard soil
26” Disc (3no.) 5mm thick, hardened (HRC>40)
Parking stand: Box or U shape
2100mmX1050mmX1150mm +20mm(L-W-H)
Main Farm: Tubular, Seamless pipe
Mast A-Fram M.S Sheet
Bearings: European standard or Equivalent
Paint: Double coat with primer after surface finish
Weight approximately 320kg(+5kg)₨ 188,700Disc Plough- 3 Disc
₨ 188,700 -
Raised Bed Shaper and Row Disc Bedders
2x disc
Rota blades 42
5mm wall sheet
Transmission box
Delivery time 11 days
One year warranty₨ 550,000Raised Bed Shaper and Row Disc Bedders
₨ 550,000 -
-
-
-
-
-
-
TMR Machine
250-300kg
RS.300000/-
Without motor/engine
15hp motor/ 20hp engine required.(15-30) animal2 Cubic meter
RS. 600000/-
Hydraulic loading Bucket with hydraulic Discharge gate, Tractor operated.
(30-60) animal4 Cubic meter Full option
RS.1500000/-
Weight Scale system
Self Hydraulic
Hydraulic loading Bucket
Hydraulic Conveyor Discharge.
(60-150) Animals6 Cubic meter Full option
RS.1850000/-
Weight Scale system
Self Hydraulic
Frount mounted Hydraulic Conveyor Discharge.
(150-250) Animal8 cubic meter full option
RS 2300000/-
Weight Scale system
Double hydraulic Discharge with conveyor
Loading Bucket
(250+ animal)₨ 300,000TMR Machine
₨ 300,000 -
-
-
-
-
-
-
-
-
Self Propelled Reaper / Multi Purpose Harvester
Model: 4G120A-C-1
Engine: 13 HP Petrol Engine– 4 Feet Cutting Area
– Cutting Height: 1 inches above ground
– Recoil Start
– Automatic Clutch System with brakes
– Extra Wide TyresCrops
– Barseem, Lohsan, Rodegrass
– Wheat
– Rice
– Jawar, Makai, Bajra
– Any crop/fodder– 1 acre harvesting in 1 hour
2- 2.5 Litre petrol consumption per acre₨ 530,000 -
Maize Threasher with 7HP Petrol Engine
Maize Threasher Machine
– Model 5TY-60G
– Speed(r/min) 1600
– Rated Power 7HP Petrol Engine
– Productivity(Kg/h) 1500₨ 60,000 -
Maize Threasher with 3 HP Motor
Maize Threasher Machine
– Model 5TY-60
– Speed(r/min) 1600
– Rated Power 3HP
– Rated Voltage(V) 220V,50hZ
– Productivity(Kg/h) 1500₨ 50,000Maize Threasher with 3 HP Motor
₨ 50,000 -
COMMANDOS ELECTRIC SPRAYER
BATTERY SPRAYER
SINGLE PUMP & MANUAL — BOTH WORKING OPTIONS
BATTERY TIMING 3 hours ( 25 TANKs per battery )₨ 6,000₨ 6,500COMMANDOS ELECTRIC SPRAYER
₨ 6,000₨ 6,500 -
Multicut BAJARA
300 BAG of 2 KG
FOR 1 acre need 2 bags ( only water req )
Productivity 3 cutting season.Delivery charges apply as per kg
₨ 350₨ 450Multicut BAJARA
₨ 350₨ 450 -
BAJARA SEEDs BY
Bag Weight 2.5 KG PER acre
Proudvtive 30-35 Per /MAAN-₨ 1,400₨ 1,500BAJARA SEEDs BY
₨ 1,400₨ 1,500 -
MAXIM ( FODDER )
Australian Brand
1kg /3000 PKR
Available in 2 , 8 & 20 kg
Take benefits up to 5 Years
First Production time ( 50 to 60 days )
reproduction right every 20 to 25 days,₨ 3,200MAXIM ( FODDER )
₨ 3,200 -
ROADGRESS SEED ( MATRA AGRI )
Australian Brand
Take benefits up to 5 Years
First Production time ( 50 to 60 days )
reproduction right every 20 to 25 days,₨ 3,200ROADGRESS SEED ( MATRA AGRI )
₨ 3,200 -
-
-
